6082 is a high-strength Al-Mg-Si aluminum alloy with excellent welding performance, corrosion resistance and formability, widely used in transportation, machinery manufacturing, shipbuilding. Inquire now!
6082 aluminum alloy is a typical representative of heat-treatable, hardened aluminum alloys in the aluminum-magnesium-silicon (6xxx series) family. Its core characteristic is its balanced performance, combining good ductility and weldability with excellent resistance to stress corrosion cracking and moderate corrosion resistance, and good stability in atmospheric and freshwater environments.
Alloy 6082 is known as a structural alloy. Its key feature lies in its ability to develop a balanced combination of strength and toughness after heat treatment (e.g., T6 temper). Its tensile strength, yield strength, and fatigue resistance better meet the core load-bearing and deformation-resistance requirements of structural components.
It also offers excellent formability and stress corrosion resistance, allowing it to stably withstand static and dynamic loads in structural applications. Consequently, it is widely used in load-bearing structural components in fields such as engineering machinery and transportation.
Elements | Mn | Fe | Mg | Si | Cu | Zn | Ti | Cr | Others (each) | Other (total) | Al |
% Present | 0.4-1.0 | 0.0-0.5 | 0.6-1.2 | 0.7-1.3 | 0.0-0.1 | 0.0-0.2 | 0.0-0.1 | 0.0-0.25 | 0.05 | 0.15 | Remainder |
Alloy | 6082 aluminum sheet |
Thickness | 0.2-200 mm |
Length | 30-2500 mm |
Width | 500-13000 mm |
Tempers | Tensile strength Rm(MPa) | Yield strength Rp0.2(MPa) | Elongation A50mm (%) |
O (annealed) | 170-210 | ≤ 110 | ≥ 18 |
T4 (solution treated + natural aging) | 240-280 | 110-150 | ≥ 14 |
T6 (solution treated + fully artificially aged) | 310-350 | 270-310 | ≥ 8 |
T651 (T6 base + stretching to relieve internal stress) | 310-350 | 270-310 | ≥ 8 |
AA6082
HE30
DIN 3.2315
EN AW-6082
ISO: Al Si1MgMn
A96082
Plain sheet with a PVC coating on one side
Coated Aluminum sheet
Aluminum tread plate
Brushed aluminum sheet
Anodized aluminum sheet
Mirror finish aluminum sheet
Rail Transit: Subway/light rail car frames and floors
Ships/Yachts: Small and medium-sized hull side panels and deck supports
Commercial Vehicles/Trucks: Carriage floors and frame crossmembers
New Energy Vehicles: Battery pack frames and chassis supports
Architectural Structures: Curtain wall support keels
Decorative Functional Components: outdoor billboard panels
Door and Window Frames: extruded profiles for high-end high-rise doors and windows
Construction Machinery
Trusses
Bridges
Cranes
We adopts standard export shipping packaging and bundles steel strips according to the size of the aluminum sheet. According to our delivery experience, a 20-foot container can hold 22 tons of aluminum, and a 40-foot container can hold 25 tons of aluminum. Also, we can customize the packaging according to the needs of customers.
1. Cut to size: We can provide any size you need.
2. Dedicated person: A reliable sales person is always at hand.
3. On-time delivery: We have special team to ensure on-time delivery.
4. Reliable after-sale service: We have staff to deal with your appeal any time.
