5454 aluminum has medium to high strength and outstanding corrosion resistance, widely used automotive structural components, marine parts, chemical equipment. Rich specifications for you. Inquire now!
5454 aluminum sheet belongs to the Al-Mg series of rust-resistant aluminum alloys, with magnesium as the core strengthening element (content 2.4%-3.0%), combined with manganese, chromium, and other elements to optimize performance, possessing both medium to high strength and excellent overall properties.
It exhibits outstanding corrosion resistance, especially against seawater and chloride-based corrosive media. Its stress corrosion cracking threshold is superior to similar 5083 and 5754 alloys, making it suitable for harsh environments.
Furthermore, it possesses stable physical properties and is widely used in automotive structural components, marine parts, chemical equipment, pressure vessels, and other fields, achieving a balance between lightweight design and reliability.
Chemical composition(%)
Alloy | Mn | Fe | Mg | Si | Cr | Ti | Zn | Cu | Other (each) | Others (total) | Al |
5454 | 0.5-1.0 | 0.0-0.4 | 2.4-3.0 | 0.0-0.25 | 0.05-0.2 | 0.0-0.2 | 0.0-0.25 | 0.0-0.1 | 0.0-0.05 | 0.0-0.15 | Balance |
Alloy | 5454 alloy |
Tempers | O, H111, H22, H34,H38,H14,H12 |
Thickness(mm) | 0.2-250 |
Width(mm) | 100-2650 |
Maximum Length | 12000 |
Tempers | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |
O (Annealed) | 215 - 285 | ≥85 | ≥19 |
H12 (Work-hardened) | 230 - 270 | ≥150 | ≥15 |
H14 (Work-hardened) | 250 - 290 | ≥180 | ≥10 |
H32 (Work-hardened + Stabilized) | 250 - 305 | ≥180 | ≥12 |
H34 (Work-hardened + Stabilized) | 340 - 380 | ≥280 | ≥10 |
H38 (Work-hardened + Stabilized) | ≥380 | ≥320 | ≥6 |
Plain sheet
Plain sheet with a PVC coating on one side
Coated Aluminum sheet
Aluminum tread plate
Aluminum tanker sheet
Anodized aluminum sheet
Marine aluminum sheet
A95454
3.3537
AlMg2.5Mn
A5454
AlMg3Mn
Al2.7Mg0.8MnCr
N51
Chemical tankers
Marine related facilitate
Fuel transport tanks
Road salt resistant frames
LNG transport tanks
Pressure vessels
Boiler components
Brewing tanks and systems
Food processing equipment
Freezing systems
Liquid nitrogen containers
Cryogenic storage systems
Aerospace auxiliary structures
1. It is covered with paper or film to avoid scratches.
2. The second protective layer is plastic or kraft paper packaging.
3. Wooden pallets and steel strips are used to prevent aluminum sheet deformation.
4. Wooden boxes and pallets with fumigation markings are used to package export goods.
5. If you have other packaging requirements, feel free to contact us directly.
1. Cut to size: We can provide any size you need.
2. Dedicated person: A reliable sales person is always at hand.
3. On-time delivery: We have special team to ensure on-time delivery.
4. Reliable after-sale service: We have staff to deal with your appeal any time.
